12V 775 High-Speed DC Motor (High Torque)
A powerful 775 brushed DC motor (12–24V) delivering high torque and up to 9000 RPM.
LKR 1,500
In stock
Key features
- 12–24V DC (optimal 12V)
- 3500–9000 RPM
- High torque, heavy-duty
- Ball-bearing construction
- 5mm output shaft
- For power tools, robotics and CNC
Island-wide delivery
Genuine parts
Easy returns
The 775 is a rugged, high-torque brushed DC motor built for demanding jobs. Running on 12–24V, it spins from 3500 up to 9000 RPM depending on load, and its ball bearings keep it smooth, quiet and long-lasting. A popular choice for power tools, drills, CNC spindles and heavy-duty robotics.
Specifications
- Voltage: 12–24V DC (optimal at 12V)
- Speed: 3500–9000 RPM (varies with load)
- Current: ~0.5A no-load, ~3–10A under load
- Body: ~42mm diameter × ~67mm length
- Shaft: ~5mm diameter, ~17mm length
- Ball-bearing construction
- Weight: ~300g
